Technical Specification of Platelet Incubator
Type	Tabletop Model
Door	Single-pane tempered glass door provides a secure and shatter-resistant barrier while allowing for clear visibility of the stored platelet bags
Controller	Microcontroller-based temperature recorder and controller unit (TRCU) positioned at eye level for better visibility
Temperature Range	+22°C with temperature variations of ±1°C
Working Environment	Extremely hot environmental temperatures of up to +43°C with Humidity 5% to 95% RH and atmospheric pressures ranging from 600 to 1060 hp.
Thermal Printer (optional)	50 millimetre (Fitted in body)
Audio Visual Alarms system	Temperature Low, Door Open, Temperature High, System ok, Agitation off, Cooling Mode, Battery Low, Heating Mode
Compressor	Hermetically sealed
Internal lamp	LED tube for uniform lighting
Display	4 x 7 segment LED display with resolution of 0.5
Temperature Chart Recorder	Six inch 7-day ink-based pressure sensitive circular chart recorder with ±1°C accuracy and also has chart changing and set button facility
Battery Backup	2 hours Inbuilt battery backup with 12V, 2.3 Ah rechargeable battery for ensure continuous operation of the display and alarm during power failure
Data Logger	USB Data logger (Optional)
Power Supply	220-240V, 50 Hz single phase AC power supply
Power Protection	MCB provides an extra layer of protection against electrical overloads and short circuits

Technical Specification of Platelet Agitator
Trays	8 sliding tray stainless steel 304 removed trays for cleaning
Material of Trays	Stainless Steel 304
Type of agitation	Movement -Flat bed agitation.
Cycle Motion	65 +/-7 cycles per minutes
Pause function	10 Sec
Agitating mechanism	230V AC induction motor controlled
Displacement Range	36mm
Indication	LED Indication for blown fuse
Power Supply	220-240V, 50 Hz single phase AC power supply
