Deep Freezer -40° C
–40°C Deep Freezer is purpose-built for secure storage of temperature-sensitive biological materials, including stem cells, plasma, and viruses. Designed for reliability, efficiency, and compliance, it delivers stable sub-zero performance with a robust, corrosion-resistant build and advanced temperature recovery technology, ideal for healthcare, diagnostics, and biotech environments.
Precise Cooling Range (–10°C to –40°C)
Maintains consistent ultra-low temperatures for safe biological storage.
Advanced Refrigeration System
Compression cycle technology enables rapid freezing, with CFC-free insulation and cooling for an eco-friendly solution.
Superior Build & Durability
99.97% pure copper tubing (suction, freezer, and condensing) enhances performance and longevity.
Smart Temperature Monitoring
Internal memory stores temperature & alarm data, allowing real-time display and transfer to a PC for compliance and analysis.
Enhanced User Convenience
Auto door closure, anti-condensation hotline, and provision for defrosting ensure hassle-free operation and maintenance.
Compliance & Longevity Assurance
CE certified (Notified Body No.1282) and built for a minimum 10-year lifespan, with IEC 61010, IEC 60335-1, and IEC 60335-2-24 electrical safety standards.
Type of Cabinet | Vertical/Upright |
Outer Material of Cabinet | Corrosion resistance CRCA/GI powder coated steel (18swg) |
Inner Material of Cabinet | High grade corrosion-resistant SS 304 (Stainless Steel) |
PUFF Insulation- CFC free | Cabinet: 127 mm Door: 115 mm |
Castors Wheels | Four castor wheels (two lockable and two unlockable) for easy mobility. |
Ground Clearance | 100 mm |
Door | Solid lockable door with handle, provision for padlock, and four polystyrene-insulated inner doors, supported by electrically heated doors for quick opening in frost conditions. |
Compressor | Heavy-duty, maintenance-free Hermetically sealed compressor |
Refrigerants | CFC-free, high-efficiency non flammable refrigeration |
Condensing | Skin condensing with inner and air-cooled grooved aluminum fins |
Pull down time | 04 Hours |
Operating Temperature | –10°C to -40°C adjustable with accuracy of ±0.1°C |
Temperature uniformity | ±2˚C |
Environmental Condition | Maximum +43°C with Humidity 5% to 95% RH |
Control System | Fully programmable microprocessor-controlled system with membrane keypad and password-protected eye-level digital display for precise temperature setting. |
Temperature Monitoring System | 24×7 temperature recorder/data logger with USB data download and optional IoT (cloud- based) monitoring and 7-day inkless chart recording. |
Display | Digital Temperature Display 7” Touch Screen. |
Alarms | Audible and visual alarm system for over/under temperature, overheat/overcool, power or system failure, door open, door ajar conditions voltage faults, and low battery conditions. |
Battery Backup (Optional) | 24/48/72-hour backup for temperature display, security lock, alarm system, and temperature chart recorder to ensure continuous recording in case of power failure with auto recharging facility. |
Access port | Provision of connecting LN2/CO2 Backup system for maintaining the set temperature during power failure (Optional) |
Noise level | 50 dBA |
Power supply | 210-240 V AC, 50-60 Hz +10% |
