Make

MarkEn

Observation Head

Ergonomic binocular observation head 30° inclined, 360° rotatable design

Body Construction

Sturdy, stable base with ergonomic focus controls; epoxy powder-coated metal body, heat-treated and resistant to reagents, solvents, and disinfectants

Frame Construction

Rigid, vibration-free microscope frame

Material Protection

Corrosion-proof, acid-proof, stain-resistant metallic parts

Eyepiece

Paired PL 10×/22 mm high-eyepoint wide-field eyepieces with ≥22 mm field of view, diopter adjustment on both sides, antifungal treatment, and integrated pointer

Nosepiece

Quintuple or sextuple revolving nosepiece with coded/motorized option, ball-bearing mechanism, click stops, ribbed grip, and dust-proof caps

Optical System

Infinity-corrected optical system with ergonomic coaxial coarse and fine focusing

Objective

High-NA Plan Achromatic objectives including 4X, 10X, 20X, 40X, and 100X oil immersion suitable for bright field, phase contrast, DIC, and fluorescence applications

Mechanical Stage

Right-hand ceramic-coated XYZ stage with motorized/coaxial operation, ≤100 nm step accuracy, 200 × 150 mm travel range, 120 × 130 mm stage size, and dual-slide holder

Condenser

Swing-out universal condenser (NA 0.9) or Abbe condenser (NA 1.2) for bright field, dark field, phase contrast, and DIC

Filter Cube System

High-efficiency 480 nm & 535 nm LED illuminators with Blue filter cube comprising 480 nm excitation band-pass filter and 510 nm long-pass emission filter, and Green filter cube comprising 535 nm excitation band-pass filter and 575 nm long-pass emission filter.

Fluorescence System

LED fluorescence illumination system with an average LED life of more than 8,000 hours, or 4–6 position turret fluorescence attachment with narrow bandpass filter sets for DAPI, FITC/GFP, TRITC/Cy3, and optional Cy5 fluorescence imaging

Brightfield Illumination

Built-in Koehler illumination with transmitted LED/halogen light source, providing uniform field illumination, high color reproduction, and LED life of up to 50,000+ hours

Fluorescence Illumination

20 W LED fluorescence illuminator with excitation wavelengths of 385 nm, 475 nm, 550 nm, and 621 nm or 100 W mercury/xenon/metal halide lamp with remote intensity control

Camera

Scientific HD sCMOS/CMOS camera with pixel size ≤6.5 μm, resolution ≥2048 × 2048 pixels (4 MP or higher), ≥5 MP imaging capability, color/mono modes, USB 3.0 connectivity, and image acquisition software

Sensor Cooling

Thermoelectric cooling for reduced thermal noise

Imaging Software

Same-make image acquisition and image enhancement software supporting image stitching, Z-stack imaging, cell counting, and image analysis, with compatibility for major digital imaging software platforms such as Nikon NIS-Elements, Leica LAS X, Zeiss ZEN, Olympus cellSens, and Micro-Manager.

Computer System

i5 processor-based workstation with Windows 10 OS, 8 GB RAM, 1 TB HDD, 18-inch color TFT display, keyboard, mouse, and standard UPS.

Power Supply

220–250V AC, 50 Hz with durable power cord and plug as per Indian standards

Electrical Safety

ON/OFF switch with proper fuse holder

Upgrade Capability

Upgradable to fluorescence and dark field microscopy
